First, the cause of air compressor noise
To effectively reduce the noise of the air
compressor, we first need to understand the cause of its noise. Air compressor
noise mainly comes from the following aspects:
1. Mechanical noise:
Moving parts: The piston, screw, bearing
and other moving parts inside the air compressor will produce mechanical
vibration and friction during high-speed operation, resulting in noise.
Unbalanced forces: Unbalanced forces of
moving parts can also cause vibration and noise.
2. Airflow noise:
Intake and exhaust: When the air enters and
exits the air compressor, strong airflow noise will be generated due to changes
in flow rate and pressure.
Eddy noise: When the air flow in the
pipeline, due to the uneven flow rate, eddy currents will be generated,
resulting in noise.
3. Electromagnetic noise:
Motor: During the operation of the air
compressor, electromagnetic noise will be generated due to the action of the
electromagnetic force.
4. Resonance noise:
Structural resonance: When the natural
frequency of each component of the air compressor is the same as the external
excitation frequency, it will generate resonance, thereby amplifying the noise.
Second, an effective way to reduce the
noise of air compressors
In view of the causes of the above noise,
the following effective noise reduction measures can be taken:
2.1 Mechanical noise control
1. Optimized design:
Reduce vibration: Reduce vibration and
friction of moving parts by optimizing the structural design of the equipment.
For example, the use of balance technology, shock absorption devices, etc.
Improve accuracy: improve the machining
accuracy of parts and reduce vibration and noise caused by assembly gaps.
2. Use shock absorber:
Shock pad: The shock pad is installed
between the air compressor and the foundation, which can effectively absorb
vibration and reduce noise transmission.
Spring shock absorbers: The use of spring
shock absorbers can further reduce vibration transmission.
3. Soundproof enclosure:
Fully enclosed soundproof cover: The air
compressor is completely enclosed in the soundproof cover, which can
effectively block the propagation of noise.
Sound absorbing materials: Install sound
absorbing materials, such as rock wool, glass wool, etc., on the inner wall of
the sound enclosure to further improve the sound insulation effect.
4. Regular maintenance:
Lubrication maintenance: Regularly
lubricate and maintain the air compressor to ensure smooth operation of moving
parts and reduce friction noise.
Fastener inspection: check and tighten the
connected parts regularly to prevent vibration and noise caused by loosening.
2.2 Air flow noise control
1. Optimize intake and exhaust systems:
Muffler: The installation of mufflers at
the intake and exhaust ports can effectively reduce airflow noise.
Diffuser tube: diffuser tube design, reduce
airflow speed, reduce eddy noise.
2. Pipeline design:
Reasonable layout: Reasonable design of
pipeline direction, avoid sharp turns and sudden cross sections, reduce airflow
resistance.
Flexible connections: Flexible connections,
such as rubber hoses, are used at pipe connections to effectively absorb
vibration and noise.
3. Filter device:
High efficiency filter: Use high efficiency
filter to remove impurities and particles in the air and reduce airflow noise.
2.3 Electromagnetic noise control
1. Choose low noise motor:
Variable frequency motor: The use of
variable frequency motor can adjust the speed according to the load change,
reduce electromagnetic noise.
Quiet bearings: Choose quiet bearings to
reduce the noise of mechanical friction.
2. Electromagnetic shielding:
Shielding cover: Electromagnetic shielding
cover is installed on the outer layer of the motor and cable, which can
effectively block the transmission of electromagnetic noise.
2.4 Resonant noise control
1. Frequency analysis:
Spectrum analysis: The noise spectrum of
the air compressor is analyzed to determine the resonance frequency.
Adjusting parameters: By adjusting the
operating parameters of the device, the resonance frequency is avoided.
2. Structure optimization:
Increase stiffness: Increase the stiffness
of the equipment structure and reduce the possibility of resonance.
Damping materials: Damping materials are
used in key parts to absorb vibration energy and reduce resonance noise.
Reducing the noise of air compressor is a
systematic project, which needs to start from many aspects, including the
control of mechanical noise, airflow noise, electromagnetic noise and resonance
noise. By adopting comprehensive measures such as optimal design, installation
of mufflers, use of sound enclosures, and adoption of frequency conversion
technology, the noise level of air compressor operation can be effectively
reduced, and a quiet and comfortable working environment can be created for
enterprises.
